Tinned Lug 6 AWG - #10 Stud Size - 10 Pack
Creating a strong connection is essential to every electrical system. By using closed-end lugs, users get not only durability but longevity as well. Pacers closed-end lugs are tin-plated and have no exposed seams. This means that they are ideal for marine applications. What makes them ideal is the fact that they can be used to create waterproof connections. When used with epoxy heat shrink, the closed end lug will fully envelop the conductor. This leaves nothing exposed to the elements. To use, simply strip your wire or cable to the proper length. Once this is complete, slide the lug over the exposed wire, making sure the insulation butts up to the edge of the lug.
Now, crimp the lug using the correct tool, and youre done. Add epoxy lined heat shrink for added durability. Pacers closed-end lugs are available in 8 AWG to 4/0 AWG wire sizes. The available stud sizes include #10, 1/4, 5/16, 3/8, and 1/2. Selecting the correct closed-end lug isnt an easy task. Contact a Pacer expert today with any questions that you may have.
Features:
- Tin Plated
- No exposed seams
- Rated for 600V
- Made from seamless tubes of 99.9% copper for higher conductivity
- Designed for stranded copper wires
- Larger pad area for better contact
- Cable size and stud hole stamped on pad
- Can be crimped or soldered
- Highly controlled flare to allow easy cable insertion
- Tight barrel to pad transition provides longer usable barrel length
Compliances:
- E.T.P. (Electrolytic Tough Pitch) CDA-110
- ASTM-B-152 copper rated at 100% conductivity
- UL CSA Approved
- RoHS Compliant
- Exceeds SAE Conductivity STD J163 J1811
Specifications:
- Wire AWG: 6
- Stud Size: #10
- Length: 1.266
- Width: 0.438
- Clearance: 0.344
- Package Size:10
The Pacer Group TAE6-10R-10 Tinned Lug is designed to create reliable and durable connections for your electrical systems. Featuring a tinned finish, these closed-end lugs are perfect for marine applications, ensuring that your connections remain waterproof and protected from the elements. The seamless design and lack of exposed seams enhance longevity, making them an essential component for any professional or DIY electrical project.
With a rating of 600V, these lugs are constructed from seamless tubes of 99.9% copper, providing superior conductivity for stranded copper wires. The larger pad area ensures better contact, while the highly controlled flare allows for easy cable insertion. Simply strip the wire to the proper length, slide the lug over the exposed wire, and crimp it using the right tool to establish a robust connection. For added durability, consider using epoxy-lined heat shrink.
Available in a convenient 10-pack, the Pacer Tinned Lug is versatile for various wire sizes and stud sizes, making it a must-have for any electrical toolkit. Whether you are a professional or a hobbyist, these lugs will meet your needs with compliance to industry standards, ensuring quality and safety.
Features:
* Tin Plated for corrosion resistance: Tin Plated for corrosion resistance
* No exposed seams for enhanced durability: No exposed seams for enhanced durability
* Rated for 600V for reliable performance: Rated for 600V for reliable performance
* Made from seamless tubes of 99.9% copper for higher conductivity: Made from seamless tubes of 99.9% copper for higher conductivity
* Designed specifically for stranded copper wires: Designed specifically for stranded copper wires
* Larger pad area for improved electrical contact: Larger pad area for improved electrical contact
* Cable size and stud hole clearly stamped on pad: Cable size and stud hole clearly stamped on pad
* Can be crimped or soldered for flexible installation options: Can be crimped or soldered for flexible installation options
* Highly controlled flare for easy cable insertion: Highly controlled flare for easy cable insertion
* Tight barrel to pad transition for longer usable barrel length: Tight barrel to pad transition for longer usable barrel length
